OUR PROJECTS
我們的實績案例
ALLJET designs and manufactures high performance customized ultra-precision motion solutions
for a diverse variety of customers’ requirements.
我們擁有技術領先且經驗豐富的專業團隊，在自動精密機械領域的廣大範疇中耕耘多年，
除了發展專業的深度，更不斷堅持創新，並針對創新研發申請專利，
因此，我們具備絕對的自信，為您量身打造客製化及量產的服務，
以下皆為我們的技術實績：
為保護客戶，部分圖片模糊處理
奈米精度對位定位平臺
精密交叉滾柱/ 可達奈米精度
高剛性
平面度穩定
光學尺
可另搭配θ軸
可選用 鐵芯式/無鐵芯式線馬
應用：AOI、雷射加工……等
複合真空多孔陶瓷吸盤
雙軸堆疊型 X-Y STAGE
高速度、高精度
應用彈性
光學尺
可另搭配θ軸
可選用 鐵芯式/無鐵芯式線馬
防塵方式可搭配
應用：AOI、雷射加工……等
自動封膜機
鋁膜捲帶式 送料（R TO R）
手臂取放料 / TRAY 進料
電腦控制熱壓溫度
自動變距（專利）
生產速度 35000pcs / 8hr
生技醫療產業適用
Semi-Automatic Exposure Machine
半自動曝光機
Product application：Semiconductor industry
Alignment accuracy : 1μm
Wafer size : 12”、8”
Semi-auto mask aligner system
Bottom side version Top side version double sides
Full-Auto High Speed Printing System For PCB
國內知名大廠使用中
PCB自動化視覺定位噴印設備
自動對位的噴印設備
應用產業：PCB（國內知名大廠使用中）
Repeatability重覆精度：±1.5μm
Accuracy絕對精度：±2.5μm
Maximum speed速度：800mm/sec
Auto loader／unloader 自動進出料
Dicing System
半導體製程切割機
Product application：Semiconductor industry
Auto loader／unloader
Maximum speed：1000mm/sec
Repeatability：±0.5μm
Accuracy：±1μm
Laser Cutting System For FPC
雷射軟板切割機
Product application : PCB/ FPC
Repeatability：1μm
Accuracy：±2.5μm
Maximum speed：600㎜/sec
半導體探針測試平臺
Product application : Semiconductor industry
Repeatability : ±0.5μm
Accuracy : ±1.5μm
Maximum speed : 300mm/sec
Linear Stages Module
單軸線馬模組
Single axis／multi-axis：suitable for each industry application
Multipurpose stage：customer self-assembly
Base：granite／aluminum／carbon steel
Flexible structure
真空陶瓷盤
Size：450 x 450mm
Flatness：±3.5μm
Automated Mask Optical Inspector (Building-in Air Bearing Structure System)
全氣浮AOI光罩檢測機
◆ Product application：Semiconductor industry
◆ High-precision accuracy (<1μm, industry-first)
◆ High straightness：3μm／1.2m
◆ High flatness：<4μm／150x150mm2／aluminum base
Laser Scribing/
Drilling Equipment for Ceramics
陶瓷鑽孔／劃線機
◆ Product application：Passive component industry
◆ Repeatability：1μm
◆ Accuracy：±1μm
◆ Maximum speed：300mm/sec
Automated Nanoimprint
Lithography System
自動奈米塗佈轉印機
◆ Product application：Semiconductor industry
◆ Loader／spin-coating／baking／stamping／unloader
◆ Wafer size：4”, 6”
◆ Auto loader／unloader
Automated Scribing／Drilling Equipment for Solar Cell
全自動SOLAR CELL劃線／鑽孔機
◆ Product application：Solar cell industry
◆ Scribing／drilling／marking
◆ Clamping easy broken material (sheet thickness=0.1mm/6”)
◆ Auto loader／unloader (pick and place)
Automated Alignment with Exposure System (BSV/TSV Double Sides)
自動正反雙面對準曝光機
◆ Product application：Semiconductor industry
◆ Exposure accuracy：0.1μm
◆ Wafer size：2”, 4”, 6”
◆ Yield：120-150 UPH
3D Solder Paste Inspector
3D SPI 鍚膏檢測機
◆ Product application：PCB industry
◆ Ironless linear motors driving, zero backlash, low cogging force
◆ Repeatability：±1.5μm
◆ Fully in-line system
2D Automated Optical Inspector
2D AOI PCB檢測機
◆ Product application：PCB industry
◆ Ironless linear motors driving, zero backlash,
low cogging force
◆ Inspection area：510~380×450mm
◆ Fully in-line system
Gantry Structure Stage/
Air Bearing Structure
全氣浮龍門平臺
◆ Product application：PCB industry
◆ Maximum speed of x：300mm/sec
◆ Maximum speed of y：1000mm/sec
◆ Straightness：3μm／1.7m(granite base)
◆ Orthogonality：±2.5arc-sec (±0.00069°)
Gantry Structure Stage／
Twin Side-Driving
龍門雙同動平臺
◆ Multipurpose stage (in-line／off-line)
◆ Yaw-direction compensation
◆ Travel stroke：500x600mm
◆ Maximum speed：1000mm/sec
